Khoom Description
UF2000-B ultrasonic flowmeter, crafted rau lub sij hawm ntev hauv internet ntsuas nrog ib tug robust IP 67- ntsuas converter thiab IP68- ntsuas transducers rau kev txhim kho durability. Nws ua haujlwm rau ntau hom kev siv ua kua, suav nrog cov kua dej ntshiab, dej siv tau yooj yim, tshuaj lom neeg, dej phwj tuaj, dej rov qab, dej txias, dej ntws, thiab cov dej cog qoob loo. Nrog nws yooj yim phab ntsa-mounting installation ntawm lub 'meter' thiab clamp-on installation ntawm probes, tsis muaj yeeb nkab nkag mus thiab ntau lawm yuav tsum tau, zoo tagnrho rau ntau haiv neeg thiab ib puag ncig daim ntaub ntawv.
Khoom nta
- Kev ntsuas qhov tseeb ntawm 1%.
- Tus tsim muaj zog nrog IP67 convertor thiab IP68 transducers.
- Kev ntsuas dav dav, haum rau cov yeeb nkab loj ntawm DN15mm txog DN6000mm.
- Slexible nrog peb txoj kev teeb tsa: phab ntsa mounted, DIN-rail mounted, thiab tawg-pov thawj lub thawv mounted.
- Kev ntsuas kub / hluav taws xob txhawb nqa los ntawm kev sib txuas ntawm qhov ntsuas kub hloov pauv.
Khoom Specification
|
Tus tswv |
Qhov tseeb |
±1% |
|
Zaub |
2X20 cim LCD nrog lub teeb pom kev zoo, txhawb cov lus Suav, Askiv thiab Ltalis |
|
|
Teeb liab tso zis |
1 txoj kev 4 ~ 20mA tso zis, hluav taws xob tsis kam 0~ 1K, raug 0. 1% (yeem) |
|
|
1 txoj kev OCT mem tes tso zis (Pulse dav 6 ~ 1000ms, default yog 200ms) |
||
|
1 txoj kev Relay tso zis |
||
|
Teeb liab tso zis |
3 txoj kev 4 ~ 20mA cov tswv yim, qhov tseeb 0. 1%, tau txais cov teeb liab xws li kub, xovxwm thiab qib kua |
|
|
Txuas qhov kub hloov pauv Pt100, tuaj yeem ua tiav qhov ntsuas kub / lub zog |
||
|
Data Interface |
Insulate Rs485 serial interface, txawj tej yam ntxiv cov flow meter software los ntawm lub computer, txhawb lub MODBUS |
|
|
Yeeb Nkab Installation Condition |
Cov khoom siv yeeb nkab |
Hlau, Stainless hlau, Cam khwb cia hlau, tooj liab, Cement yeeb nkab, PVC, Aluminium, iav steel khoom, liner tau tso cai |
|
Txoj kab uas hla |
DN32 ~ 6000 hli |
|
|
Ncaj yeeb nkab |
Transducer installation yuav tsum txaus siab: upstream10D, downstream 5D, 30D los ntawm lub twj tso kua mis |
|
|
Ib puag ncig ua haujlwm |
Qib tiv thaiv |
Tus tswv tsev: IP67; Flow Sensor: IP68 |
|
Kub |
Tus tswv tsev: -20 ~ 60 ; flow sensor: -30 ~ 160 |
|
|
Cov av noo |
Tus tswv tsev: 85% RH; Flow sensor tuaj yeem ntsuas hauv qab dej, dej tob ^ 2m (transducer kaw kua nplaum) |
|
|
Fais fab mov |
DC8 ~ 36V lossis AC85 ~ 264V |
|
Khoom Dimensions
Cim npe nrov: Tuam Tshoj Clamp ntawm Ultrasonic Flow Meter Manufacturers thiab lwm tus neeg - Factory Price
Khoom nta
- Kev ntsuas qhov tseeb ntawm 1%.
- Tus tsim muaj zog nrog IP67 convertor thiab IP68 transducers.
- Kev ntsuas dav dav, haum rau cov yeeb nkab loj ntawm DN15mm txog DN6000mm.
- Slexible nrog peb txoj kev teeb tsa: phab ntsa mounted, DIN-rail mounted, thiab tawg-pov thawj lub thawv mounted.
- Kev ntsuas kub / hluav taws xob txhawb nqa los ntawm kev sib txuas ntawm qhov ntsuas kub hloov pauv.
Khoom Dimensions
Khoom Specification
|
Tus tswv |
Qhov tseeb |
±1% |
|
Zaub |
2X20 cim LCD nrog lub teeb pom kev zoo, txhawb cov lus Suav, Askiv thiab Ltalis |
|
|
Teeb liab tso zis |
1 txoj kev 4 ~ 20mA tso zis, hluav taws xob tsis kam 0~ 1K, raug 0. 1% (yeem) |
|
|
1 txoj kev OCT mem tes tso zis (Pulse dav 6 ~ 1000ms, default yog 200ms) |
||
|
1 txoj kev Relay tso zis |
||
|
Teeb liab tso zis |
3 txoj kev 4 ~ 20mA cov tswv yim, qhov tseeb 0. 1%, tau txais cov teeb liab xws li kub, xovxwm thiab qib kua |
|
|
Txuas qhov kub hloov pauv Pt100, tuaj yeem ua tiav qhov ntsuas kub / lub zog |
||
|
Data Interface |
Insulate Rs485 serial interface, txawj tej yam ntxiv cov flow meter software los ntawm lub computer, txhawb lub MODBUS |
|
|
Yeeb Nkab Installation Condition |
Cov khoom siv yeeb nkab |
Hlau, Stainless hlau, Cam khwb cia hlau, tooj liab, Cement yeeb nkab, PVC, Aluminium, iav steel khoom, liner tau tso cai |
|
Txoj kab uas hla |
DN32 ~ 6000 hli |
|
|
Ncaj yeeb nkab |
Transducer installation yuav tsum txaus siab: upstream10D, downstream 5D, 30D los ntawm lub twj tso kua mis |
|
|
Ib puag ncig ua haujlwm |
Qib tiv thaiv |
Tus tswv tsev: IP67; Flow Sensor: IP68 |
|
Kub |
Tus tswv tsev: -20 ~ 60 ; flow sensor: -30 ~ 160 |
|
|
Cov av noo |
Tus tswv tsev: 85% RH; Flow sensor tuaj yeem ntsuas hauv qab dej, dej tob ^ 2m (transducer kaw kua nplaum) |
|
|
Fais fab mov |
DC8 ~ 36V lossis AC85 ~ 264V |
|
